BTD48-12S100D
BELLNIX
Images are for reference only.
Please see Product Specifications
for details.
Product Specifications
| Category | Board Mounted Power Supply DC DC Converters |
| Manufacturer | BELLNIX |
| Series | BTD (10W) |
| Type | Isolated Module |
| Voltage - Input (Max) | 76V |
| Voltage - Input (Min) | 36V |
| Voltage - Output 1 | 12V |
| Current - Output (Max) | 1A |
| Number of Outputs | 1 |
| Efficiency | 88% |
| Operating Temperature Range | -40°C ~ 85°C (With Derating) |
| Features | Adjustable Output, Remote On/Off |
| Applications | ITE (Commercial) |
| Mounting Type | Through Hole |
| Size / Dimension | 1.41"L x 0.89"W x 0.33"H(35.9mm x 22.6mm x 8.4mm) |
・This information is intended to provide a brief overview of the item.
・For a more comprehensive explanation of this product, please refer to the manufacturer's
official data sheet.
In Stock: 4
MOQ:1
SPQ:1
Scheduled Incoming Stock (back-order): 60
| Quantity | Unit Price | |
|---|---|---|
| 1 - 29 | $35.989 | |
| 30 - 89 | $34.986 | |
| 90 - 149 | $34.986 | |
| 150 - 299 | $31.739 | |
| 300 - 599 | $31.45 | |
| 600 - | $30.60 | |
| - | - | |
| - | - | |
