SKHHCRA010
ALPS ALPINE
Images are for reference only.
Please see Product Specifications
for details.
Documents
Product Specifications
| Actuator Length | 1.5 mm |
| Color | Yellow |
| Contact Current Rating | 50 mA |
| Contact Plating | Silver |
| Contact Resistance | 100 mΩ |
| Current Rating | 50 mA |
| Electrical Life | 200 kcycles |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Max Operating Temperature | 85 °C |
| Max Voltage Rating (DC) | 12 V |
| Mechanical Life | 200 kcycles |
| Min Operating Temperature | -30 °C |
| Mount | Through Hole |
| Number of Positions | 2 |
| Operating Force | 5.1 N |
| Orientation | Straight |
| Radiation Hardening | No |
| Termination | Solder |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12 V |
・This information is intended to provide a brief overview of the item.
・For a more comprehensive explanation of this product, please refer to the manufacturer's
official data sheet.
In Stock: 858
MOQ:1
SPQ:1
Scheduled Incoming Stock (back-order): 0
| Quantity | Unit Price | |
|---|---|---|
| 1 - 19 | $0.65 | |
| 20 - 49 | $0.536 | |
| 50 - 99 | $0.359 | |
| 100 - 299 | $0.30 | |
| 300 - 499 | $0.26 | |
| 500 - 999 | $0.252 | |
| 1,000 - 3,999 | $0.246 | |
| 4,000 - | $0.242 | |
