AC電源コネクタ　

Manufacturer	Connector Type	Filter Type	Voltage Rating - Appliance Inlet	Current Rating - Filter	Current Rating - Appliance Inlet	Accomodates a Fuse	Fuse Holder, Drawer	Termination	Switch Features	Features	Panel Cutout Dimensions

解除	解除	解除	解除	解除	解除	解除	解除	解除	解除	解除	解除

適用されたフィルタ：

ヒット検索結果：7件 / 型名：指定なし / ステイタス：すべて / 数量：0PCS~ / メーカー：すべて / シリーズ：EK

1/1 ページ目を表示

チェックした内容をまとめて見積依頼する

検索結果をダウンロード

1

選択	在庫タイプ仕入先ランク	サプライヤ	在庫ロケーション	写真データシート	型名メーカ名	在庫数	デートコード	単価	最低発注数量/以降発注単位	出荷予定日	情報コアスタッフ型名	ECADモデル	Manufacturer	Series	Connector Type	Filter Type	Voltage Rating - Appliance Inlet	Current Rating - Filter	Current Rating - Circuit Breaker	Current Rating - Appliance Inlet	Connector Style	Accomodates a Fuse	Fuse Holder, Drawer	Number of Positions	Product Overview	Termination	Ingress Protection	Switch Features	Features	Applications	Automotive	Mounting Type	Panel Cutout Dimensions	Panel Thickness	Material Flammability Rating	Approval Agency
			他社在庫		03EK3 DELTA ELECTRONICS						Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange 梱包形態：バラ品コアスタッフ型名：zp2216-1144-1021-ND@0	電子CAD:Quadceptで利用可能	Delta Electronics	EK	Receptacle, Male Blades - Module	Filtered (EMI, RFI) - Commercial	115/250VAC	-	-	3A	IEC 320-C14	Yes (Fuse Not Included)	Fuse Holder, Twin Fused	3		Quick Connect	-	Switch On-Off	Voltage Selector			Panel Mount, Flange	Rectangular - 29.00mm x 60.20mm	-	-	CSA, UL, VDE
			他社在庫		03EK3M DELTA ELECTRONICS						Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange 梱包形態：バラ品コアスタッフ型名：zp2216-1144-1013-ND@0	電子CAD:Quadceptで利用可能	Delta Electronics	EK	Receptacle, Male Blades - Module	Filtered (EMI, RFI) - Commercial, Medical	115/250VAC	-	-	3A	IEC 320-C14	Yes (Fuse Not Included)	Fuse Holder, Twin Fused	3		Quick Connect	-	Switch On-Off	Voltage Selector			Panel Mount, Flange	Rectangular - 29.00mm x 60.20mm	-	-	CSA, UL, VDE
			他社在庫		06EK3 DELTA ELECTRONICS						Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange 梱包形態：バラ品コアスタッフ型名：zp2216-603-1259-ND@0	電子CAD:Quadceptで利用可能	Delta Electronics	EK	Receptacle, Male Blades - Module	Filtered (EMI, RFI) - Commercial	115/250VAC	-	-	6A	IEC 320-C14	Yes (Fuse Not Included)	Fuse Holder, Twin Fused	3		Quick Connect	-	Switch On-Off	Voltage Selector			Panel Mount, Flange	Rectangular - 29.00mm x 60.20mm	-	-	CSA, UL, VDE
			他社在庫		06EK3A DELTA ELECTRONICS						Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange 梱包形態：バラ品コアスタッフ型名：zp2216-1144-06EK3A-ND@0	電子CAD:Quadceptで利用可能	Delta Electronics	EK	Receptacle, Male Blades - Module	Filtered (EMI, RFI) - Commercial	-	6A	-	-	IEC 320-C14	Yes (Fuse Not Included)	Fuse Holder, Twin Fused	3		Quick Connect	-	Switch On-Off	Voltage Selector			Panel Mount, Flange	Rectangular - 29.00mm x 60.20mm	-	-	CSA, UL, VDE
			他社在庫		06EK3M DELTA ELECTRONICS						Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange 梱包形態：バラ品コアスタッフ型名：zp2216-603-1261-ND@0	電子CAD:Quadceptで利用可能	Delta Electronics	EK	Receptacle, Male Blades - Module	Filtered (EMI, RFI) - Commercial, Medical	115/250VAC	-	-	6A	IEC 320-C14	Yes (Fuse Not Included)	Fuse Holder, Twin Fused	3		Quick Connect	-	Switch On-Off	Voltage Selector			Panel Mount, Flange	Rectangular - 29.00mm x 60.20mm	-	-	CSA, UL, VDE
			他社在庫		06EK4M DELTA ELECTRONICS						Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange 梱包形態：その他コアスタッフ型名：zp2216-1144-06EK4M-ND@0	電子CAD:Quadceptで利用可能	Delta Electronics	EK	Receptacle, Male Blades - Module	Filtered (EMI, RFI) - Commercial	-	-	-	-	IEC 320-C14	Yes (Fuse Not Included)	Fuse Holder, Twin Fused	3		Quick Connect	-	Switch On-Off	-			Panel Mount, Flange	Rectangular - 60.20mm x 28.96mm	-	-	CSA, UL, VDE
			他社在庫		06EKM1 CURTIS INDUSTRIES						Power Entry Connector Receptacle, Male Blades IEC 320-C14 Panel Mount, Flange 梱包形態：バラ品コアスタッフ型名：zp2216-364-1026-ND@0	電子CAD:Quadceptで利用可能	Curtis Industries	EK	Receptacle, Male Blades	Filtered (EMI, RFI) - Commercial	250VAC	6A	-	6A	IEC 320-C14	No	-	3		Quick Connect - 0.250" (6.3mm)	-	-	-			Panel Mount, Flange	Rectangular - 32.98mm x 23.11mm	-	-	CSA, UL, VDE
